2 pulgadas-4 pulgadas
Ruixin
Herramienta de tracción tipo SB
Aleación de acero y aleación de níquel
chinabaoji
Línea alámbrica y línea de acero
Estándar
The SB pulling tool is one of the types of pulling tool whose function is to pull out any subsurface tool whose fishneck latching is blocked by some sort of debris inside the oil well. Bracetool explains SB Pulling Tool Pulling tools falls under the well workover and intervention processes and are used to maintain the life of an oil well.
Size | Actual OD | Fishing neck | Connection | Grasping diameter |
2＂ | 1.77＂ | 1.375＂ | 15/16-10UN | 1.375＂ |
2.5＂ | 2.18＂ | 1.375＂ | 15/16-10UN | 1.75＂ |
3＂ | 2.84＂ | 2.313＂ | 1-1/16-10UN | 2.313＂ |
4＂ | 3.67＂ | 2.313＂ | 1-1/16-10UN | 3.125＂ |
More customized parts are available upon request.
SB type pulling tool purpose is to get connected with the fishing latch of the subsurface tool to retrieve it when this subsurface tool’s fishing latch is covered or blocked by the debris inside. This tool jars down the shear tool and helps in either retrieving the subsurface tool or either setting the subsurface tool.
1. Before lowering the tool, inspect whether the connection threads of the tool are loose.
2. Maintain it in time after use.
The SB pulling tool is one of the types of pulling tool whose function is to pull out any subsurface tool whose fishneck latching is blocked by some sort of debris inside the oil well. Bracetool explains SB Pulling Tool Pulling tools falls under the well workover and intervention processes and are used to maintain the life of an oil well.
Size | Actual OD | Fishing neck | Connection | Grasping diameter |
2＂ | 1.77＂ | 1.375＂ | 15/16-10UN | 1.375＂ |
2.5＂ | 2.18＂ | 1.375＂ | 15/16-10UN | 1.75＂ |
3＂ | 2.84＂ | 2.313＂ | 1-1/16-10UN | 2.313＂ |
4＂ | 3.67＂ | 2.313＂ | 1-1/16-10UN | 3.125＂ |
More customized parts are available upon request.
SB type pulling tool purpose is to get connected with the fishing latch of the subsurface tool to retrieve it when this subsurface tool’s fishing latch is covered or blocked by the debris inside. This tool jars down the shear tool and helps in either retrieving the subsurface tool or either setting the subsurface tool.
1. Before lowering the tool, inspect whether the connection threads of the tool are loose.
2. Maintain it in time after use.
